Brand Name: | Copeland |
Model Number: | ZB114KQE-TFD-550 |
MOQ: | 1 piece |
Price: | discussed |
Delivery Time: | 6-10 Days |
Payment Terms: | T/T, Western Union |
Product name | Copeland |
Model | ZB114KQE-TFD-550 |
Application | HVAC |
Package | wooden case |
MOQ | 1 piece |
Piston Type | Closed |
Displacement | 43.3m³/h |
Refrigerant | R404A/R507/R22 |
Oil change[dm3] | 3.30 |
Voltage | 380/420V~3 ;50HZ |
Model NO | Cindensate Temperature | The evaporation temperature ºC(R22/50HZ) | Sets/Pallet | |||||
-12 | -10 | -5 | 0 | 5 | 10 | |||
ZB15KQ-PFJ | 40 | 3300 | 3550 | 4350 | 5200 | 6250 | 7400 | 16 |
ZB21KQ-PFJ | 40 | 4650 | 5050 | 6200 | 7450 | 8850 | 10500 | 16 |
ZB26KQ-PFJ | 40 | 5100 | 5500 | 6800 | 8200 | 9850 | 11700 | 16 |
ZB15KQ-TFD | 40 | 3300 | 3550 | 4350 | 5200 | 6250 | 7400 | 16 |
ZB21KQ-TFD | 40 | 4650 | 5050 | 6200 | 7450 | 8850 | 10500 | 16 |
ZB26KQ-TFD | 40 | 5100 | 5500 | 6800 | 8200 | 9850 | 14070 | 16 |
ZB29KQ-TFD | 40 | 6230 | 6790 | 8290 | 9970 | 11800 | 14400 | 16 |
ZB38KQ-TFD | 40 | 7300 | 8000 | 9950 | 12200 | 14650 | 17300 | 16 |
ZB45KQ-TFD | 40 | 9400 | 10200 | 12400 | 14900 | 17800 | 21000 | 16 |
ZB48KQ-TFD | 40 | 10390 | 11285 | 13700 | 16436 | 19574 | 23199 | 16 |
ZB58KQ-TFD | 40 | 11800 | 12950 | 16100 | 19600 | 19574 | 28000 | 12 |
ZB66KQ-TFD | 40 | 13950 | 15100 | 18400 | 22200 | 26500 | 31500 | 12 |
ZB76KQ-TFD | 40 | 16400 | 17800 | 21700 | 28500 | 30500 | 35500 | 12 |
ZB88KQ-TFD | 40 | 18800 | 20400 | 24900 | 30000 | 36000 | 42000 | 12 |
ZB95KQ-TFD | 40 | 19500 | 21400 | 26500 | 32000 | 38200 | 45200 | 12 |
ZB114KQ-TFD | 40 | 23200 | 25500 | 31700 | 38500 | 41600 | 54500 | 12 |
Company Information
We were able to service our clients in refrigeration and air conditioning on a worldwide scale by operating on the ground of the Chinese market. We can work with our customers to increase the quality and lower the cost of their products by providing the greatest product quality and excellent service.
We have sales channels all around the world and buyers who are satisfied with our items.
We want to establish close working ties with our distributors and partners in this quickly growing industry so that we may develop our business together.
Welcome to our company's website!
Features and Benefits
Offload Boot Technology
Compression components are separated from each other after shutdown. Comprehensive pressure balance inside the compressor,
No additional starter is required.
High strength DU bearing
Upper main and drive bearings
Space Age Materials
(1) Porous permeable bronze
(2) Polytetrafluoroethylene PTFE coating
In the case of incomplete lubrication
Extend runtime
Very small coefficient of friction
Our Service
Pre-sales: We provide assistance to our customers, provide valid information according to the requirements of our guests, answer questions, leave a professional impression, and lay the foundation for future sales.
After-sales: After the products are sold, the professionals provide training services, check and maintain the products regularly, if there is problems for the quality,Will solve it for customers in time.
FAQ
When do you make deliveries?
3 to 10 working days following payment, delivery takes place.
What is the trade Term?
EXW or FOB ShenZhen
What is your main products?
- Bitzer compressors
- Scroll compressors: CR,VR, ZB ,ZR, ZF,ZP SERIES
- Semi-hermetic compressors: DL,D2,D4,D6,D8 SERIES
- Performer compressors: SM, SZ, SH SERIES
- Commercial compressors: FR, SC SERIES
- Maneurop piston compressors:MT, MTZ, NTZ, MPZ SERIES
- Secop compressor, Carrier(Carlyle) compressor
- Hitachi compressor,Daikin compressor, Sanyo compressor
- Tecumseh compressor, LG compressor, Mitsubishi compressor
- Toshiba compressor, Panasonic compressor, Embraci Aspera compressor
- Also Bitzer, Carel, Dixell original valves, controls and selected parts
- TE, TDE, TGE, PHT SERIES TERMOSTATIC EXPANSION VALVES
- ETS SERIES EXPANSION VAVLES,
- EVR SERIES ECPANSION VAVLES AND
- KP1,KP5,KP15 SERIES PRESSURE CONTROLS
- DCL DML LIQUID LINE FILTER DRIERS
Which port does you ship from?
Guangzhou/Shenzhen.
How about the Shipping method?
Based on the product and quantity, by air, ship or express.
Are you a factory or a trading company?
We have our own factory
![]() |
