| Brand Name: | Copeland |
| Model Number: | ZB19KQE-TFD-558 |
| MOQ: | 1 piece |
| Price: | discussed |
| Delivery Time: | 6-10 Days |
| Payment Terms: | T/T, Western Union |
| Product name | Copeland |
| Model | ZB19KQE-TFD |
| Application | HVAC |
| Package | wooden case |
| MOQ | 1 piece |
| Piston Type | Closed |
| Displacement | 6.8m³/h |
| Refrigerant | R404A;R507;R134a;R22 |
| Oil change[dm3] | 1.30 |
| Voltage | 380/420V~3 ;50HZ |
| Model NO | Cindensate Temperature | The evaporation temperature ºC(R22/50HZ) | Sets/Pallet | |||||
| -12 | -10 | -5 | 0 | 5 | 10 | |||
| ZB15KQ-PFJ | 40 | 3300 | 3550 | 4350 | 5200 | 6250 | 7400 | 16 |
| ZB21KQ-PFJ | 40 | 4650 | 5050 | 6200 | 7450 | 8850 | 10500 | 16 |
| ZB26KQ-PFJ | 40 | 5100 | 5500 | 6800 | 8200 | 9850 | 11700 | 16 |
| ZB15KQ-TFD | 40 | 3300 | 3550 | 4350 | 5200 | 6250 | 7400 | 16 |
| ZB21KQ-TFD | 40 | 4650 | 5050 | 6200 | 7450 | 8850 | 10500 | 16 |
| ZB26KQ-TFD | 40 | 5100 | 5500 | 6800 | 8200 | 9850 | 14070 | 16 |
| ZB29KQ-TFD | 40 | 6230 | 6790 | 8290 | 9970 | 11800 | 14400 | 16 |
| ZB38KQ-TFD | 40 | 7300 | 8000 | 9950 | 12200 | 14650 | 17300 | 16 |
| ZB45KQ-TFD | 40 | 9400 | 10200 | 12400 | 14900 | 17800 | 21000 | 16 |
| ZB48KQ-TFD | 40 | 10390 | 11285 | 13700 | 16436 | 19574 | 23199 | 16 |
| ZB50KQ-TFD | 40 | 10600 | 11660 | 14350 | 17400 | 20800 | 24700 | 12 |
| ZB58KQ-TFD | 40 | 11800 | 12950 | 16100 | 19600 | 19574 | 28000 | 12 |
| ZB66KQ-TFD | 40 | 13950 | 15100 | 18400 | 22200 | 26500 | 31500 | 12 |
| ZB76KQ-TFD | 40 | 16400 | 17800 | 21700 | 28500 | 30500 | 35500 | 12 |
| ZB88KQ-TFD | 40 | 18800 | 20400 | 24900 | 30000 | 36000 | 42000 | 12 |
| ZB95KQ-TFD | 40 | 19500 | 21400 | 26500 | 32000 | 38200 | 45200 | 12 |
| ZB114KQ-TFD | 40 | 23200 | 25500 | 31700 | 38500 | 41600 | 54500 | 12 |
Features and Benefits
High energy efficiency ratio
Scrolls run in rather than wear
Better performance as runtime increases
High volumetric efficiency
Offload Boot Technology
Compression components are separated from each other after shutdown.
Comprehensive pressure balance inside the compressor,
No additional starter is required.
Lower noise and vibration levels
Smooth sound spectrum and soft sound quality
Compression chambers are always symmetrically distributed
low unbalanced stress
High precision manufacturing process
No need for vibration absorbers
High strength DU bearing
Upper main and drive bearings
Space Age Materials
(1) Porous permeable bronze
(2) Polytetrafluoroethylene PTFE coating
In the case of incomplete lubrication
Extend runtime
Very small coefficient of friction
Why choose us?
1.Sufficient supply, fast delivery
2.Offer one-stop service.
3.We sale variety brands of Compressor,meet your all requirement
FAQ
What is the MOQ?
Typically, our MOQ is 1 set.
How much does it cost?
The pricing is determined on the quantity and various brands.
What time do you deliver?
Delivery occurs 3 to 10 working days after payment.
What is your main products?
Scroll compressor
Piston compressor
Semi-hermetic compressor
Freezer compressor
Rotary compressor
Refrigeration accessories
What is the payment schedule?
Western Union, T/T
What is the term used in trade?
FOB ShenZhen or EXW
From which port do you ship?
Guangzhou/Shenzhen.
The shipping method, how about it?
Depending on the merchandise and the amount, via express, ship, or air.
What about the support and follow-up?
Quality is guaranteed, and there is a 1-year warranty.
Are you a manufacturing or trade business?
We are one of the largest refrigeration equipment manufacturers in China.
