| Model Number: | 4NES-20Y/4NCS-20.2Y |
| MOQ: | 1 piece |
| Price: | US$712-1000/PC |
| Delivery Time: | 5-7 Days |
| Payment Terms: | T/T, Western Union, MoneyGram |
Production details
| SI | IP | |
| Displacement(1450 RPM 50 HZ) | 56.25m³/h | 1986.5 CFH |
| Displacement(1750 RPM 60 HZ) | 67.89 m³/h | 2397.5 CFH |
| No.of cylinder * bore * stroke | 4*70mm*42mm | 4*2.76inch*1.65Inch |
| Weight | 150 kg | 331 lb |
| Max,pressure(LP/HP) | 19/32 bar | 275/464 psi |
| Connection suction line | 42mm-1 5/8” | 42mm-1 5/8” |
| Connection discharge line | 28mm-1 1/8” | 28mm-1 1/8” |
| Motor version | 1 | 1 |
| Starting current(Rotor locked) | 97.0 A Y/158.0 A YY | 176.0 A |
| Motor voltage(more on request) | 380-420V Y-3-50 HZ | 440-480V Y-3-60 HZ UL |
| Max operating current | 33.2 A | 33.2 A |
|
Supply r134 r410a refrigeration compressor 20hp 4NES-20Y 4NCS-20.2Y 4NES-20Y / 4NCS-20.2Y |
|
| Brand | |
| Model no. | 4NES-20Y / 4NCS-20.2Y |
| Motor Size( HP) | 20 |
| Motor version | 1 |
| Displacement Type(m 3/h) | 56.2 |
| oil charge (dm3) | 2.6 |
| Voltage | 380-420V/3PH/50Hz or 440-480V/3PH/60Hz |
| No of cylinders | 4 |
| Refregrant | R-22, R134, R410A |
| Certification | VDE, TUV and CE |
| weight(kg) | 150 |
| Place Of Original | Germany |
| packing | wooden case |
FAQ
1,What is your MOQ?
Our MOQ is usually 1 set.
2, What is the price?
The price is decided by Quantity and Different Brand.
3,What is your delievery time?
The time of delievery is 7-15 working days after payment.
4,What is the shipping port?
We ship the goods via Shenzhen China.
5,What is your payment terms?
TT/Western Union
6,What is the location of your company?
We are in Shenzhen City,Guangdong Province,China.If you would like to have a visit, you are warmly welcome.
7,What is your main products?
Focus on:
Semi-hermetic compressor
Hermetic Compressor
Refrigeration Compressor Unit
8, How about samples?
Sample Lead Time: 2 or 3 working days
Sample Fee:
1).It's free for all for a regular customer
2).for new customers, we will charge first, it is fully refundable when order confirmed.
|
|
