Semi Hermetic 4FES-3Y 4HP Reciprocating Compressor

Name: Semi Hermetic 4FES-3Y 4HP Reciprocating Compressor
Brand: Shenzhen Ruifujie Technology Co., Ltd.
SKU: 4FES-3Y(4FC-3.2Y)
Price: Negotiable USD
Availability: InStock

Model Number:	4FES-3Y(4FC-3.2Y)
MOQ:	1 piece
Price:	US$712-1000/PC
Delivery Time:	5-7 Days
Payment Terms:	T/T, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Type:

Refrigeration Compressor

Application:

Refrigeration Parts

Certification:

ROHS, CE

Power:

4HP

Cylinder:

Weight:

82 KG

Refrigerant:

R404 R407C R134A

Color:

Green

Warranty:

1 Year

Power Source:

AC POWER

Packaging Details:

Standard Wooden Package

Supply Ability:

10000Pieces/Year

Highlight:

4HP Bitzer Semi Hermetic Compressor

4FES-3Y

Product Description

1. Product parameter(Specification)

Model	Displ. @1450r/min	Cylinders	Oil charge	Weight	Discharge line		Suction line
Model	m³/h	Cylinders	dm³	Kg	mm	in	mm	in
2KES-05Y	4.06	2	1	43	12	1/2"	16	5/8"
2JES-07Y	5.21	2	1	43	12	1/2"	16	5/8"
2HES-1Y	6.51	2	1	44	12	1/2"	16	5/8"
2HES-2Y	6.51	2	1	45	12	1/2"	16	5/8"
2GES-2Y	7.58	2	1	45	12	1/2"	16	5/8"
2FES-2Y	9.54	2	1	45	12	1/2"	16	5/8"
2FES-3Y	9.54	2	1	47	12	1/2"	16	5/8"
4FES-3Y	18.1	4	2	82	16	5/8”	22	7/8”
4FES-5Y	18.1	4	2	86	16	5/8”	22	7/8”
4EES-4Y	22.7	4	2	84	16	5/8”	28	1 1/8”
4EES-6Y	22.7	4	2	86	16	5/8”	28	1 1/8”
4DES-5Y	26.8	4	2	86	22	7/8”	28	1 1/8”
4DES-7Y	26.8	4	2	89	22	7/8”	28	1 1/8”
4CES-6Y	32.5	4	2	91	22	7/8”	28	1 1/8”
4CES-9Y	32.5	4	2	91	22	7/8”	28	1 1/8”
4VES-6Y	34.7	4	2.6	129	22	7/8”	28	1 1/8”
4VES-7Y	34.7	4	2.6	129	22	7/8”	28	1 1/8”
4VES-10Y	34.7	4	2.6	139	22	7/8”	28	1 1/8”
4TES-8Y	41.3	4	2.6	134	28	1 1/8”	35	1 3/8”
4TES-9Y	41.3	4	2.6	134	28	1 1/8”	35	1 3/8”
4TES-12Y	41.3	4	2.6	414	28	1 1/8”	35	1 3/8”
4PES-10Y	48.5	4	2.6	139	28	1 1/8”	35	1 3/8”
4PES-12Y	48.5	4	2.6	139	28	1 1/8”	35	1 3/8”
4PES-15Y	48.5	4	2.6	147	28	1 1/8”	42	1 5/8”
4NES-12Y	56.2	4	2.6	141	28	1 1/8”	35	1 3/8”
4NES-14Y	56.2	4	2.6	141	28	1 1/8”	35	1 3/8”

2.Production details

	SI	IP
Displacement(1450 RPM 50 HZ)	18.05 m³/h	637.4 CFH
Displacement(1750 RPM 60 HZ)	21.78 m³/h	769.2 CFH
No.of cylinder * bore * stroke	441mm39.3mm	41.61inch1.55inch
Weight	82 kg	181 lb
Max,pressure(LP/HP)	19/32 bar	275/464 psi
Connection suction line	22mm-7/8”	22mm-7/8”
Connection discharge line	16mm-5/8”	16mm-5/8”
Motor version	2	2
Starting current(Rotor locked)	44.2 A	47.5A
Motor voltage(more on request)	380-420V Y-3-50 HZ	440-480V Y-3-60 HZ UL
Max operating current	9.5 A	9.5 A

Semi Hermetic 4FES-3Y 4HP Reciprocating Compressor 0
